The 8" 1500LB Triple Offset Metal Seated Butterfly Valve is specially designed to handle extreme conditions in industries requiring high-pressure and high-temperature performance. Its triple offset design eliminates seat wear, ensuring a longer service life and zero-leakage operation.

Triple Offset Design:
Provides bubble-tight sealing and eliminates contact between the seat and seal during operation.

High-Pressure Capability:
Rated for Class 1500, ensuring reliable performance under extreme conditions.

Metal-to-Metal Seat:
Equipped with Stellite hard-facing for superior durability and high-temperature resistance.

Robust Construction:
Made with high-grade materials to withstand challenging industrial environments.

Enhanced Lifespan:
Minimised wear extends operational reliability and reduces maintenance requirements.

• Body: Carbon Steel or Stainless Steel (CF8M).
• Disc: Stainless Steel with Stellite overlay.
• Seat: Metal-to-metal hard-faced.
• Stem: Anti-blowout stainless steel.

• Nominal Diameter (DN): DN200 (8").
• Pressure Rating: Class 1500 (PN250).
• Connection Type: Flanged, compliant with ASME B16.5.
• Face-to-Face Dimensions: API 609 standard.

• Design and Manufacture: API 609, ASME B16.34.
• Pressure Testing: API 598 compliance.
• Flange Standards: ASME B16.5 compatibility.

• Oil & Gas: Suitable for high-pressure and high-temperature operations in pipeline systems.
• Power Generation: Designed for steam and hot water flow control.
• Chemical Processing: Effective in handling aggressive and corrosive media.
• Industrial Systems: Reliable in cooling and heating systems under extreme conditions.

The 8" 1500LB High Temperature, High Pressure Metal Seated Triple Offset Butterfly Valve is engineered for the most demanding applications, offering exceptional sealing and performance.

Designed for high-pressure and high-temperature environments, this valve features a metal-seated design that ensures tight sealing and extended service life. Its triple offset construction reduces wear and tear, making it ideal for industries such as power generation, refining, and chemical processing where durability is key.

This valve is built to withstand extreme conditions, providing reliable performance with minimal maintenance.

Choose the 8" 1500LB high-temperature, high-pressure metal-seated triple offset butterfly valve for ultimate sealing and durability.
