Y pattern 3 way ball valve with stainless steel
  • Y pattern 3 way ball valve with stainless steel
  • Y pattern 3 way ball valve with stainless steel
  • Y pattern 3 way ball valve with stainless steel
  • Y pattern 3 way ball valve with stainless steel
  • Y pattern 3 way ball valve with stainless steel
  • Y pattern 3 way ball valve with stainless steel
  • Y pattern 3 way ball valve with stainless steel
  • Y pattern 3 way ball valve with stainless steel
  • Y pattern 3 way ball valve with stainless steel
  • Y pattern 3 way ball valve with stainless steel
向上
向下

Y pattern 3 way ball valve with stainless steel

  • Product description:

    Three way ball valve commonly with T and L type,but this is Y type. Three-way ball valves are mainly used to shut off, distribute and change the flow direction of the medium in the pipeline.

Similar items

read more

  • Details
  • Description
  • Download

Valve Description

Body Material Ball:1.4408 Seat:PTFE
Nominal Pressure PN16
Nominal Diameter DN65
End Connection RF
Operation type Bare Shaft
Test & Inspection ISO 5208
Design Standard ISO 17292

Special Notes:We also can do special material according to customer\'s requirements

Valve Details

Flange face finish

The ASME B16.5 code requires that the flange face(raised face and flat face) has a specific roughness to ensure that this surface be compatible with the gasket and provide a high quality seal.

Standard Bolts & Nuts

DBV ball valve adopts the standard bolts and nuts. It could extend the valve longer service life.

Series Number

The ASME B16.5 code requires that the flangeEvery valve with a unique identified number and Tag number from clients

Every valve in DBV with clear typecasting

Our big size butterfly valves also can comply with the leakage class A.(Zero Leakage).
